SN74LS132N NAND Schmitt triger

  • Image 1
Price:
$1.49
SKU:
COM-74LS132
Current Stock:
134
Quantity:


Product Description

These devices contain four independent 2-input NAND gates in a DIP-14 through hole package. But because of the Schmitt action, the gates have different input threshold levels for positive (VT+) and negative (VT-) signals.

Electrical Characteristics

  • Supply voltage (VCC): 5 V
  • High Level Input Voltage (VIH): 2 V
  • High Level Input Current (IIH): 40 uA
  • Low Level Input Voltage (VIL): 0.8 V
  • Low Level Input Current (IIL): -0.8 mA
  • High Level Output Voltage (VOH): 3.4 V
  • High Level Output Current (IOH): -0.8 mA
  • Low Level Output Voltage (VOL): 0.2 V
  • Low Level Output Current (IOL): 16 mA
  • Operating free-air temperature: 70°C (max)
  • Positive Threshold Voltage (VT+): 1.7 V
  • Negative Threshold Voltage (VT-): 0.9 V

Pinout


Hysteresis curve


 Datasheet
